Automatic Register Rotogravure Printing Machine Soft Package Printing Press

Ask Lasest Price
Brand Name :	Allfine
Model Number :	LC-A-H
Certification :	CE
Price :	negotiation
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	5 sets/ 80 working days
Delivery Time :	80 working days

Add to Cart

Product Details
Company Profile

Automatic Register Rotogravure Printing Machine Soft Package Printing Press

Allfine Group-20 years experience Solution

1:Label production line- flexo print machine,die cutting machine,slitting machine,inspection and rewinding machine
2:Flexible package line-water bottle label PVC,heat transfer Pet, Opp, Pe etc rotogravure printer, dry laminator, PP PE film blowing machine,bag making machine
3:Decal paper,wine and smoking package-Silk screen press machinery, wicket dryer, uv dryer
4:Paper cup production line- flexo printer. die cutting machine, paper cup making machine

1: Save material 2: Improve efficiency 3:Professional tranning 4: Factory built

Partner Manager-Jack Huang
Allfine Group

Automatic Register Rotogravure Soft Package Printing Press Machine Package Printing Computerized
rotogravure printing production line.pdf

OPP	18~60μm	PET	12~60μm
PE	40~80μm	BOPP	19~60μm
CPP	20~60μm	NY	12~50μm
PVC	20~80μm
Paper	30~80g/ m²

Color quantity	4
Max. Width of printing	800mm
Mechanical speed	320m/min
Printing speed	300m/min (Variable because of different ink, film, familiarity of operator)
Length of printing cylinder	480~1000mm
Dia. of printing cylinder	Φ120mm~Φ320mm
Color control precision	±0.10mm (Variable because of different ink, film, familiarity of operator)
Max. unwind/rewind Dia.:	Φ750mm
Tension range	3~50kgf
Tension control precision	±0.5kgf
Paper core diameter	3
Core, I.D. of raw material	Φ76mm
Pneumatic source	0.6Mpa
Impression roller pressure	370kgf
Doctor blade transverse move range	±5mm
Drying mode	Electrical heating
Heating power(power of drying)	50×6=300Kw
Mail motor	4Kw(6 SET)
Power consumption	380 KW
Machine size	22000×4400×3500(mm)
Machine weight	Near 30000kg
Automatic speed up/down to the target speed gradually
Max. speed limit can be set for different material or cylinder size
Idle or running status can be exchanged

For user prepare for:

Power resource: 3 phase X380V X 50HZ
Line power: 240kW
Pneumatic source: pressure of 6~7kg/cm²
Blower pipe: from Extract blower to main blower pipe of the machine
Extract Blower: 1.5kW, centrifugal blower
Main parts are adopted imported famous brand

Servo motor:Yaskawa
Servo motor controller: Yaskawa
Auto tension controller: touch screen + PLC(Seimens)
Vertical colored system :1 set Wuhan HUAMAO
Main motor : Yaskawa
Servo motor controller:Yaskawa
MAIN BEARING:NSK
Main low voltage apparatus :Schneider
Unwind motor:ABB
Unwinding controller:Yaskawa
mini friction air cylinder:French
Precision pressure regulating valve:French
Statement:
1. The ink types, materials, printing area will effect printing speed.
2. Since this model is one of the high-tech products, according to the design requirements, we reserve the right to change some structure and parameters in order to provide you better equipment.
Max. unwind width 850mm
Max. unwind Dia. Φ750mm
Unwind motor 2×4kW ABB
Unwinding controller Yaskawa
mini friction air cylinder French
Precision pressure regulating valve French
MAIN BEARING NKS
main low voltage apparatus Schneider
Turning speed 1r/min
Tension range 3~50kgf
Tension control precision ≤3％
Feature
Not-stop roll exchange and splicing, saving time and high efficiency
Roller exchange for stable tension with less waste
Mini friction air cylinder tension detect, function curve correct tension adjustment
Independent unwind stand for unwind diameter increase and convenient operation
