High Speed Gravure Printing Press , Rotogravure Lamination Machine 300 M/Min Working Speed

Ask Lasest Price
Brand Name :	Allfine
Model Number :	LC-A-H
Certification :	CE
Price :	negotiation
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	5 sets/ 80 working days
Delivery Time :	80 working days

Add to Cart

Product Details
Company Profile

High Speed Gravure Printing Press , Rotogravure Lamination Machine 300 M/Min Working Speed

Allfine Group-20 years experience Solution

1:Label production line- flexo print machine,die cutting machine,slitting machine,inspection and rewinding machine
2:Flexible package line-water bottle label PVC,heat transfer Pet, Opp, Pe etc rotogravure printer, dry laminator, PP PE film blowing machine,bag making machine
3:Decal paper,wine and smoking package-Silk screen press machinery, wicket dryer, uv dryer
4:Paper cup production line- flexo printer. die cutting machine, paper cup making machine

1: Save material 2: Improve efficiency 3:Professional tranning 4: Factory built

Partner Manager-Jack Huang
Allfine Group

Automatic 300 m/min Roto Gravure Printing Machine with online inspection video High Speed Electronic Line Shaftless

rotogravure printing production line.pdf

OPP	18~60μm	PET	12~60μm
PE	40~80μm	BOPP	19~60μm
CPP	20~60μm	NY	12~50μm
PVC	20~80μm
Paper	30~80g/ m²

Color quantity	4
Max. Width of printing	800mm
Mechanical speed	320m/min
Printing speed	300m/min (Variable because of different ink, film, familiarity of operator)
Length of printing cylinder	480~1000mm
Dia. of printing cylinder	Φ120mm~Φ320mm
Color control precision	±0.10mm (Variable because of different ink, film, familiarity of operator)
Max. unwind/rewind Dia.:	Φ750mm
Tension range	3~50kgf
Tension control precision	±0.5kgf
Paper core diameter	3
Core, I.D. of raw material	Φ76mm
Pneumatic source	0.6Mpa
Impression roller pressure	370kgf
Doctor blade transverse move range	±5mm
Drying mode	Electrical heating
Heating power(power of drying)	50×6=300Kw
Mail motor	4Kw(6 SET)
Power consumption	380 KW
Machine size	22000×4400×3500(mm)
Machine weight	Near 30000kg
Automatic speed up/down to the target speed gradually
Max. speed limit can be set for different material or cylinder size
Idle or running status can be exchanged

For user prepare for:

Power resource: 3 phase X380V X 50HZ
Line power: 240kW
Pneumatic source: pressure of 6~7kg/cm²
Blower pipe: from Extract blower to main blower pipe of the machine
Extract Blower: 1.5kW, centrifugal blower
Main parts are adopted imported famous brand

Statement:
1. The ink types, materials, printing area will effect printing speed.
2. Since this model is one of the high-tech products, according to the design requirements, we reserve the right to change some structure and parameters in order to provide you better equipment.
Length of printing cylinder 880~1340mm
Dia. of impression roller Φ125mm (A) 70°-75°
Max. Impression pressure 370kgf
Doctor movement ±5mm
Doctor blade pressure 10~150kgf
Every electrical heating power 50KW
Max.temperature 80℃
Main motor 4KW 6 SET Yaskawa
Servo motor controller 4 Kw 6 SET Yaskawa
MAIN BEARING NKS
Main low voltage apparatus Schneider
Structure
Individually control for every color
Double oven, external heater, oven for enclosed double circular structure, a number of return air road, into the style with a centrifugal fan
Intelligentized constant temperature control;
Sharp heat air injector;
Electrical heating and hot oil heating system.
Pneumatically open/close cabinet with guide way and trolley

High Speed Gravure Printing Press , Rotogravure Lamination Machine 300 M/Min Working Speed

Our mission:

1.Let every cost be used into the raw material to achieve high quality and high stable machine operation and long life; 2.Improve Work efficiency to save the machine cost. 3. Let every machine more Intelligent, convinient, labor saving, time saving.

1.Warranty Time:12 months/one year.
